Half-bridge ASFETs for space constrained applications feature:
- 60% lower parasitic inductance due to internal clip connection
- 30% space saving on PCB compared to LFPAK56D dual
- Flexible leads for BLR
- Industry leading low Rth(j-mb) of LFPAK ensures MOSFET junction temperature can be kept under control even in the most compact of designs
- As with all motor applications, there is a level of system vibration that cannot be dampened. LFPAK56D-HB brings a unique level of board level reliability and ruggedness.
Featured products
Featured documents
Latest videos
參數搜索
Half-bridge for space constrained motor applications
數據加載中，請稍候...參數搜索不可用。
產品
| 型號 | 描述 | 狀態 | 快速訪問 |
|---|---|---|---|
| PSMN013-40VLD | Dual N-channel 40 V, 13 mOhm logic level MOSFET in LFPAK56D (half-bridge configuration) | Production | |
| PSMN4R2-40VSH | Dual N-channel 40 V, 4.2 mOhm standard level MOSFET in LFPAK56D (half-bridge configuration) | Production |
Visit our documentation center for all documentation
Application note (1) |
|||
|---|---|---|---|
| 文件名稱 | 標題 | 類型 | 日期 |
| AN90011.pdf | Half-bridge MOSFET switching and its impact on EMC | Application note | 2025-09-10 |
